Tornio VIGERT CW6163X4000 usato in vendita

CW6163X4000 Lathe is a specific model of lathe, a machine tool used for various machining operations like turning, facing, drilling, and threading. Lathes are widely used in metalworking, woodworking, and other industries for shaping and cutting workpieces. Here’s a detailed description of the key features and components of the CW6163 Lathe:

1. Bed and Base: CW6163X4000 Lathe. The lathe typically features a sturdy bed and base, providing the foundation for the entire machine. The bed is designed to support and align the other components.
2. Paletta:  The headstock houses the main spindle, which rotates and holds the workpiece. It contains the gearing mechanism to control spindle speed and power transmission.
3. Mandrino: CW6163X4000 Lathe. The spindle is a critical component that rotates the workpiece. It is equipped with a chuck or other workholding devices to secure the workpiece during machining.
4. Contropunta: The tailstock is situated on the opposite end of the lathe from the headstock. It contains the tailstock spindle, which can move along the bed to support the workpiece and help maintain its stability during machining.
5. Tool Post and Tool Rest: CW6163X4000 Lathe.The tool post holds the cutting tools used for various operations. It can be adjusted and rotated to achieve different cutting angles. The tool rest provides support for the cutting tool during the machining process.
6. Carriage: The carriage is a moving component that holds the tool post and tool rest. It moves along the bed and cross-slide, allowing for longitudinal and transverse movements during machining.
7. Cross-slide and Compound Rest: The cross-slide moves perpendicular to the lathe’s spindle axis, enabling precise transverse cuts. The compound rest allows for both longitudinal and angular adjustments of the tool for taper turning.
